The Meraki MS series is a cloud-managed switching platform that provides enterprise-grade performance while remaining simple to deploy and operate. Designed for flexibility and scalability, these switches support access and aggregation roles without the complexity typically associated with traditional network hardware.
Starting at $1,249* (MSRP $10,556)
- Access Ports: 36-port mGig 2.5GbE + 12-port mGig 10GbE UPoE switch
- Uplink Ports: Optional modular up to 40Gb QSFP+
- Features: Optional redundant PSU, optional stacking support
- Management: Meraki Cloud Management^
*Pricing listed is not guaranteed. Prices are subject to change at any time, depending on available inventory and market pricing
^ Requires Meraki Cloud licensing
★ 100% Quality Guarantee ★
★ ISO Certified Testing Facility ★
★ Lifetime Replacement Warranty ★
★ Expertly Packed and Shipped ★
Related Content
Resources
🖺 Tech Spec Sheet
Technical Specs
| Port Configuration | • 36x Multigigabit (100M / 1G / 2.5G) RJ45 • 12x Multigigabit (100M / 1G / 2.5G / 5G / 10G) RJ45 |
| Power over Ethernet (PoE) | • Universal Power over Ethernet (UPoE/802.3bt) • Up to 60W per port |
| Performance | • Switching Capacity: 580 Gbps • Forwarding Rate: 431.54 Mpps |
| Stacking | • 480 Gbps physical stacking bandwidth • Dual dedicated 120G hardware stacking ports |
| Uplinks | • Modular uplink slots for 10G / 40G uplinks (modules sold separately) |
| Dimensions & Weight | • Dimensions (H x W x D): 1.73” x 17.5” x 22.2” • Weight: ~20.5 lbs |
Power and Thermal Specifications
- Power Supply: Ships with 1x 1100WAC power supply. Dual modular bays support up to two hot-swappable power supplies.
- Fan: 3x Hot-swap fan modules (MA-FAN-16K2).
- PoE Budget: 490W with primary 1100W PS; up to 1440W total budget with dual PSUs.
- Operating Temperature: 0°C to 45°C (32°F to 113°F).
Hardware and Management
- Cloud Management: Fully managed via the Cisco Meraki dashboard for remote troubleshooting, visibility, and zero-touch provisioning.
- Security: Supports Adaptive Policy using over-the-wire tags for scalable segmentation.
- Layer 3 Features: Static routing, OSPFv2, multicast routing, DHCP relay, and server capabilities.
