Cisco Meraki MR57

The Cisco Meraki Cloud-Managed Family of wireless access points offers the performance, security, and ease of management for any enterprise environment, no matter how big or small. No matter the requirements: WiFi-6, WiFi-6E, or WiFi-7, Meraki has a solution to exceed those needs for an outstanding user experience.

Related Content | Resources | Technical Specs

Cisco Meraki MR57

Starting at $799*

High-performance, high-density WiFi-6E Wireless Access Point

  • Uplink Ports:  2 x mGig with up to 5Gbps
  • Features: 4×4 802.11ax radios, BLE, IoT and USB support, on device security. Requires PoE++ to enable all features
  • Management: Meraki Cloud^

*Pricing listed is not guaranteed. Prices are subject to change at any time, depending on available inventory and market pricing

^ Requires Meraki Cloud Licensing

Trifecta 5-Star Certified and Lifetime Warranty Logos
★ 100% Quality Guarantee ★

★ ISO Certified Testing Facility ★

★ Lifetime Replacement Warranty ★

★ Expertly Packed and Shipped ★

Related Content

Why Is the Cisco Meraki MR57 the Wi-Fi 6E AP to Know?
BLOG: Why Is the Cisco Meraki MR57 the Wi-Fi 6E AP to Know?
Why Wi-Fi 6 and Cloud Management?
BLOG: Why Wi-Fi 6 and Cloud Management?
How to Stretch Your Budget and Improve Outcomes
BLOG: How to Stretch Your Budget and Improve Outcomes

Resources

🖺 Tech Spec Sheet

Technical Specs

  • 2.4 GHz 802.11b/g/n/ax client access radio
  • 5 GHz 802.11a/n/ac/ax client access radio
  • 6 GHz 802.11ax client access radio
  • 2.4 GHz, 5 GHz, and 6 GHz tri-band Air Marshal WIDS/WIPS, spectrum analysis, & location analytics
    radio
  • 2.4 GHz Bluetooth Low Energy radio with beacon and scanning support concurrent operation of all five
    radios
  • Integrated omni-directional antennas (4.5 dBi gain at 2.4 GHz, 5.5 dBi gain at 5 GHz, and 5.5 dBi gain at
    6GHz)
  • DL-OFDMA, TWT support, BSS coloring*
  • 4 x 4 multiple input, multiple output (MIMO) with four spatial streams on 6 GHz
  • 4 x 4 multiple input, multiple output (MIMO) with four spatial streams on 5 GHz
  • 4 x 4 multiple input, multiple output (MIMO) with four spatial streams on 2.4 GHz
  • SU-MIMO, UL and DL MU-MIMO support
  • Maximal ratio combining (MRC) & beamforming
  • 20 and 40 MHz* channels (802.11n); 20, 40, and 80 MHz channels (802.11ac Wave 2); 20, 40 and 80
    MHz channels (802.11ax)
  • Up to 1024-QAM on all three – 2.4 GHz, 5 GHz, and 6 GHz bands
  • Packet aggregation
  • Power over Ethernet: 42.5 – 57V (PoE+ and 802.3bt compliant)
  • Alternative 54V DC input via DC adapter
  • Power consumption: 30W to 40W (802.3bt)
  • Minimum power requirement: 30W (PoE+, USB is disabled)
  • Maximum power consumption: 40W
  • Power over Ethernet injector and DC adapter sold separately
  • 2x 100/1000/2.5G/5G BASE-T Ethernet (RJ45)
  • 1x DC power connector (5.5 mm x 2.5 mm, center positive)
  • All standard mounting hardware included (AIR-AP-BRACKET-2)
  • Desktop, ceiling, and wall mount capable
  • Ceiling tile rail (9/16, 15/16, or 1 ½” flush or recessed rails), assorted cable junction boxes
  • Kensington lock slot
  • Concealed mount plate with anti-tamper cable bay
  • Operating temperature: 32 °F – 104 °F (0 °C – 40 °C)
  • Humidity: 5% to 95% non-condensing
  • Mean time between failure (MTBF): 998,440 hrs at +25° C operating temperature
  • 260 mm x 260 mm x 56 mm, including desk-mount feet or mount plate
  • Weight: 1.7 kg
  • Integrated layer 7 firewall with mobile device policy management
  • Real-time WIDS/WIPS with alerting and automatic rogue AP containment with Air Marshal
  • Flexible guest access with device isolation
  • VLAN tagging (802.1q) and tunneling with IPsec VPN
  • PCI compliance reporting
  • WEP, WPA, WPA2-PSK, WPA2-Enterprise with 802.1X, WPA3 – Personal, WPA3 – Enterprise*, WPA3
  • Enhanced Open (OWE)*
  • EAP-TLS, EAP-TTLS, EAP-MSCHAPv2, EAP-SIM
  • TKIP and AES encryption
  • Enterprise Mobility Management (EMM) & Mobile Device Management (MDM) integration
  • Cisco ISE integration for guest access and BYOD posturing
  • Advanced power save (U-APSD)
  • WMM access categories with DSCP and 802.1p support
  • Layer 7 application traffic identification and shaping
  • PMK, OKC, and 802.11r for fast layer 2 roaming
  • Distributed or centralized layer 3 roaming
  • Embedded location analytics reporting and device tracking
  • Global layer 7 traffic analytics reporting per network, per device, and per application
  • One power/booting/firmware upgrade status
  • RoHS
  • For additional country-specific regulatory information, please contact Meraki sales
  • Indoor access point
  • Lifetime hardware warranty with advanced replacement included
  • MR57-HW: Meraki MR57 cloud-managed 802.11a-compatible AP
  • MA-PWR-50WAC: Meraki AC adapter for MR series
  • MA-INJ-6: Meraki MR MultiGigabit 802.3bt Injector (Power Cord Not Included)
  • Mounting bracket: AIR-AP-BRACKET-1 and AIR-AP-BRACKET-2
  • Meraki access point license required
  • IEEE Standards: 802.11a, 802.11ac, 802.11ax, 802.11b, 802.11e, 802.11g, 802.11h, 802.11i, 802.11k, 802.11n, 802.11r, 802.11w and 802.11u
  • CSA and CB 60950 & 62368
  • Conforms to UL 2043 (Plenum Rating)
  • EN 60601 Certified
  • Canada: FCC Part 15C, 15E, RSS-247
  • Europe: EN 300 328, EN 301 893
  • Australia/NZ: AS/NZS 4268
  • Mexico: IFT, NOM-208
  • Taiwan: NCC LP0002
  • For additional country-specific regulatory information, please contact Meraki Sales
  • Canada: FCC Part 15B, ICES-003
  • Europe: EN 301 489-1-17, EN 55032, EN 55024
  • Australia/NZ: CISPR 22
  • Japan: VCCI
  • Canada: FCC Part 2, RSS-102
  • Europe: EN 50385, EN 62311, EN 62479
  • Australia/NZ: AS/NZS 2772
